Professional Leak Detection in Corrigan, TX — Acoustic, Thermal & Pressure Methods
The difference between a $300 pipe repair and a $3,000 drywall-and-remediation project is often just whether the leak was found before or after excessive wall opening. Our Leak Detection service in Corrigan uses the same detection methods utilities and insurance adjusters rely on — to pinpoint the failure location before anything is cut.
The Tools Behind Accurate Leak Detection in Corrigan, TX
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Pressurized supply line leaks create a distinctive low-frequency sound as water escapes the pipe and contacts surrounding soil or structure. Our acoustic listening devices amplify this signal, filtered for background noise, so we can walk a grid pattern and triangulate the loudest point — often to within 6–12 inches of the actual break.
🌡️
Infrared Thermal Camera
Active water leaks — hot or cold — create a temperature differential on the surfaces they contact. An infrared camera shows these differentials as color-coded heat maps, revealing the wet zone inside a wall or under a floor without any cutting. A cold water leak behind drywall appears as a spreading blue-gray cool zone; a hot water leak shows the inverse.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
Tracer gas detection is the method of last resort for the most challenging cases — it adds cost and setup time. We use it when acoustic and thermal methods haven't produced a definitive location and the evidence clearly supports an active leak.
What We Locate
Leak Detection for Walls, Slabs, Pools & Irrigation in Corrigan
Hidden leaks occur in different locations throughout a property — each requiring a slightly different detection approach. Here's how we handle the most common scenarios in Corrigan, TX.
Under Slab
Slab Leak Detection
Supply lines run under or through the concrete slab in most slab-on-grade homes. When these lines fail — from corrosion, shifting, or manufacturing defects — the leak is invisible from the surface but audible to acoustic equipment. We walk the floor on a grid pattern, map the loudest detection points, and triangulate to a specific floor location, typically within a square foot.
In-Wall
In-Wall & Ceiling Leak Detection
We document the thermal anomaly, mark the approximate pipe location, and recommend a minimal access cut rather than a wide wall opening.
Water Main
Underground Supply Line Detection
Supply lines between the meter and the structure run underground and are vulnerable to corrosion, ground movement, and tree root damage. A main supply line leak shows as unusually high meter usage with all interior fixtures off, sometimes with wet ground or sinkholes along the line path. Acoustic detection locates the failure in the buried line precisely enough to minimize excavation footprint.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Irrigation system leaks in main supply lines and lateral runs are found by isolating zones with the irrigation controller and pressure-testing each zone individually. Zone by zone testing narrows the failure to the smallest possible section.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
Insurance claims for water damage from hidden leaks typically require documentation that the leak was not visible or detectable without specialized equipment. Our detection report includes: pressure test results confirming active water loss, detection method used, thermal imagery or acoustic mapping showing leak location, and technician certification information.
Our Systematic Leak Detection Approach in Corrigan
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
We start at the meter. All fixtures off, we watch the meter for 10 minutes. Movement confirms active water loss from the supply side. We also check for any visible evidence — water stains, soft floors, moisture readings with a moisture meter at suspect wall surfaces.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
Within the isolated zone, we deploy thermal imaging first — scanning walls, floors, and ceilings for moisture anomalies. Then acoustic equipment confirms the specific pipe location and narrows it to the tightest possible point. Tracer gas is added if acoustic results aren't conclusive.
4
Written Report & Repair Options
You receive a written detection report including pressure test results, detection method summary, leak location (described relative to fixed reference points), and thermal imagery. If you want us to repair the leak, we quote the repair and execute immediately. If you have your own plumber, the report gives them everything they need.
Customer Reviews
Real Leak Detection Reviews from Corrigan
★★★★★
High-efficiency home with a leak that defied normal detection. Water loss was slow — about 1.5 gallons per hour. The tech used tracer gas after pressure testing confirmed the loss but acoustic detection couldn't localize it clearly. Gas detection found the escape at a micro-fitting under the slab in the utility corridor. Impressive work.
— C. Thornton, Corrigan
★★★★★
Ceiling stain in the living room kept coming back despite two drywall patches. Masters Plumbing Service ran the thermal camera and found the wet zone was traveling from a supply line joint 9 feet away and flowing down a horizontal framing member — explaining why the patch kept failing. They marked the actual pipe location, we opened 8 inches of wall there, and the repair held. No more stain.
— B. Osei, Corrigan, TX
★★★★★
Commercial building where water costs were running 40% above baseline for six months. Masters Plumbing Service ran a systematic zone-by-zone pressure isolation across four floors, narrowed the loss to the third-floor kitchen supply branch, and located the failure with thermal imaging at a concealed valve body in the ceiling. No damage to the finished ceiling.
— T. Anand, Corrigan, TX
Common Questions
Leak Detection Questions We Answer in Corrigan
The most reliable self-check: shut off every fixture and appliance in the house, then watch the water meter for 15 minutes. Any movement — including the small leak indicator dial — means water is escaping the supply side somewhere. If the main meter dial moves with everything off, you have a leak. Call us to locate it.
The repair itself requires physical pipe access, which typically means a small, targeted opening. But that's a completely different proposition from opening large wall sections while searching for an unknown leak location.
For leaks in plastic pipe, low-pressure situations, or high-noise environments, accuracy may be lower and tracer gas becomes the preferred supplemental method.
Yes. Our written detection report includes: technician credentials, equipment identification, pressure test methodology and results, detection method description, leak location with reference measurements, and supporting thermal imagery. This is the documentation format most insurance adjusters require to approve a concealed-leak water damage claim.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
The repair quote is given before any wall or floor is opened. You know the full cost of detection + repair before anything is cut.
Service Area
Serving Corrigan and the Surrounding Corrigan, TX Region
Our detection technicians are equipped with acoustic, thermal, and tracer gas tools for the full range of leak scenarios found in Corrigan, TX homes and commercial properties.
